| Name： | TL50PP | |
|
Diameter： |
50 mm |
|
|
Color : |
Blue or white |
|
|
Material： |
100% New PP with UV protector |
|
|
Piece Per CBM： |
30 piece |
|
|
Resistance : |
UV, Chloride, Acid, Oil |
|
|
Certificate: |
FDA standard with SGS certificate, |
|
|
surface area: |
more than 95 m2/m3 |
|
|
Block size: |
1mX 1mX height(0.6m to 1.2m) |
|
|
Continue operation temperature: |
70 degree |
|
|
Max operation temperature: |
80 degree( short time) |
|
|
Sedimemtation Area: |
9m2/m3 |
|
|
Assembled : |
by plastic welded gun on site |
|
|
Application: |
Carifier or Sedimentation for drink water, municipal and industrial waster water treatment |
|
|
Service Life: |
5 to 10 years |
|
| Very robust and longlasting + simplest support system | ||
How to perform the scalping operation of AquaSust lamella clarifier?
1. Open the packing of the slant pipe filler, put the first slant pipe filler flat on the ground, take the 2d slant pipe filler on pinnacle of the first piece of filler, take a look at the incision of the slant pipe filler, it have to make certain 60 angles, and is hexagonal honeycomb, after checking is correct, begin to iron the bonding point;
2. In the hexagonal honeycomb at each ends of all the aircraft joints have to be connected, each facets of the two portions of aircraft seam requires frequency connection of extra than 4 points, in the center of the two portions of slant pipe filler airplane requires welding extra than 4 points, to make sure that the welding solid;
3. Pay interest to the rhythm of operation when warm jointing, manage the temperature, warm jointing factors shall now not be omitted;
4. Each slant pipe filler bundle as a separate ironing unit, ironing done in the area - neatly stacked:
5. Midway smash should reduce off the strength grant of the soldering iron, and to be positioned safely;
|
Items No |
TL50PP05 |
TL50PP07 |
TL50PP10 |
|
Wall Thickness |
0.5mm |
0.7mm |
1.0mm |
