| Name： | TL50PP | |
|
Diameter： |
50 mm |
|
|
Color : |
Blue or white |
|
|
Material： |
100% New PP with UV protector |
|
|
Piece Per CBM： |
30 piece |
|
|
Resistance : |
UV, Chloride, Acid, Oil |
|
|
Certificate: |
FDA standard with SGS certificate, |
|
| surface area: |
more than 95 m2/m3 |
|
|
Block size: |
1mX 1mX height(0.6m to 1.2m) |
|
|
Continue operation temperature: |
70 degree |
|
|
Max operation temperature: |
80 degree( short time) |
|
|
Sedimemtation Area: |
9m2/m3 |
|
|
Assembled : |
by plastic welded gun on site |
|
|
Application: |
Carifier or Sedimentation for drink water, municipal and industrial waster water treatment |
|
|
Service Life: |
5 to 10 years |
|
| Very robust and longlasting + simplest support system | ||
Tube settler / Lamella Clarifier Package
In a conventional clarifier, particles with a gravity greater than that of the waste water settle to the bottom of the tank over time. The closer the gravity of the particles is to the gravity of the waste water, the longer the settling process takes and the larger clarifiers must be built.Lamella clarifiers are a very cost effective alternative to conventional clarifiers because they reduce the required tank volume by a factor of 2 to 4. Lamella clarifiers consist of multiple channels that act as additional surface area, reducing the settling path of particles in the wastewater.AquaSust offers consulting and sheet Tube settler systems including sheet clarifier plate settlers, support and anti-float structures, sludge removal and effluent scrubbers.
Isometric, high stability PP tube settlers
Tube settlers are used in a wide range of applications and have different requirements. Therefore,AquaSust offers different types of tubular settler that differ in channel size, surface area, material, material thickness, dimensions and other specifications. In addition, we offer support structures, baffle walls, effluent scrubbers and other tubular sedimentator components to provide a fully integrated tubular sedimentator system from a single source supplier. AquaSust UV Tube Settlers offer the following benefits to our customers:
-
Polypropylene material extends product life
-
Higher material thickness provides high product stability (walkable design)
-
Tongue and groove system allows for easy on-site assembly
-
Large channel opening size reduces risk of clogging
